Question 1

How do I fix the joystick drift on my Revolution 5 Pro Controller?

Accepted Answer

Y-axis Inversion and Firmware UpdateWe are pleased to inform you that the issue with the Y-axis inversion, which was causing joystick drift, has been resolved several months ago. Please ensure your controller is updated with the latest firmware version to benefit from this fix.FPS Pro ModeThe FPS Pro mode is designed to provide an optimized gaming experience by deactivating the joystick's dead zone. However, this may cause slight drift if the joystick does not return exactly to its center position. To avoid this inconvenience, we recommend not activating the FPS Pro mode on both joysticks at the same time.

Question 2

Which platforms is the Revolution 5 Pro Controller compatible with?

Accepted Answer

The Revolution 5 Pro Controller is compatible with PC, PlayStation 4 and PlayStation 5. It is not compatible with Mac. To change between the different platforms settings, use the switch on the back of the controller. If you want to play on Steam, set your controller’s platform switch on PC mode.

Question 3

How do I turn off the Revolution 5 Pro Controller?

Accepted Answer

The Revolution 5 Pro Controller turns off automatically when it is not connected to a PC or a console.

Question 4

How do I reset the Revolution 5 Pro Controller?

Accepted Answer

To reset the controller, insert the tip of a paper clip into the reset hole on the back of the controller for three seconds.

Question 5

Does the Revolution 5 Pro Controller have adaptative triggers?

Accepted Answer

No, the Revolution 5 Pro doesn't have adaptative triggers. Instead, we choose to focus on durability with hall effect magnetic sensors on the triggers that last over time.

Question 6

Does the Revolution 5 Pro Controller have haptic feedback?

Accepted Answer

No, the Revolution 5 Pro Controller doesn't have haptic feedback.

Question 7

Does the Revolution 5 Pro Controller have vibrations?

Accepted Answer

Yes, the Revolution 5 Pro Controller includes a vibration feature. The vibrations only work on PC games and PlayStation 4 games. On PlayStation 5 games, the controller will not vibrate.

Question 8

Does the Revolution 5 Pro Controller have the macro feature?

Accepted Answer

No, it doesn't support the macro feature because it isn't compatible with Esport regulations.

Question 9

Can I buy spare parts separately? Where can I buy them?

Accepted Answer

You will be able to buy spare parts for easy repairs through the MyNacon portal on Nacongaming. Stay tuned for more information.

Question 10

Can I use another dongle for my Revolution 5 Pro Controller?

Accepted Answer

No. For compatibility reasons, you can only use the dedicated dongle for your controller.

Question 11

How can I remap buttons on the Revolution 5 Pro Controller?

Accepted Answer

Classic modeYou can access the customisation options that follow without the need for any app: Mapping of the four rear shortcut buttons. Trigger travel data range through the trigger stopper position. Audio control through the touch pad. To map the rear shortcuts: Press and hold the Multi-function button for three seconds. The light ring around the right joystick starts flashing. Press the rear shortcut button that you want to program. The profile LED, that is linked to the selected rear shortcut, lights up. Press the button that you want to associate with the shortcut. The profile LED flashes three times to indicate that the mapping is applied to the selected shortcut. Repeat these steps for each shortcut or if you want to change an existing setting. Press the Multi-function button to leave the mode and save your settings. The light ring stops flashing. Advanced modeThis mode is the most complete customisation tool available with more than 60 variations of settings. To access the advanced mode, download the Revolution 5 Pro app here.Your controller is pre-loaded with four profiles so you can experience the range of features. You can create and share your profiles with your friends and the gaming community. Profile 1: Racing/Sports. For racing and sports games. Profile 2: FPS. With a reactive curve on your left joystick for quick movement and a progressive curve on the Right joystick for precision aiming. Profile 3: Arcade/Fighting. With an instant curve on the left and right joysticks for a quicker reaction time. Profile 4: Infiltration. With an ultra-reactive curve on the left joystick for quick movement and a delayed curve on the light joystick for precision actions.

Question 12

How do I customise the Revolution 5 Pro Controller profiles?

Accepted Answer

The controller has five pre-set profiles (one in Classic mode and four in Advanced mode). You can choose the one that better fits your gaming style, or you can fully customise the ones in Advanced mode. Install the Revolution 5 Pro companion app. Plug your Revolution 5 Pro Controller into your PC or Mac. Make sure that the controller has the following settings: The Mode button is set to Wired. The Platform button is set to PS5 or PS4. The Advanced/Classic switch is set to Advanced. Launch the app. Follow the on-screen instructions to customise your profile. Exit the app to save your changes. If you turn off or disconnect the controller without exiting the app, the changes will not be saved. To go from one profile to another, set the Advanced/Classic switch to Advanced and press the Profile button.

Question 13

How do I customise the audio settings on the Revolution 5 Pro Controller?

Accepted Answer

On PCConnect your headset directly to your PC. You can only use the built-in adapter of the controller on PlayStation 4 and PlayStation 5. This means that you won't be able to use these audio functions on PC.On PlayStation 4/PlayStation 5You can use the Multi-function button to adjust your audio settings. When you use this mode, the light ring around the right joystick flashes in white, blue and purple until you have finished using the microphone gain and equalizer functions.

Question 14

How do I pair a device on my Revolution 5 Pro Controller with Bluetooth?

Accepted Answer

Bluetooth audio is supported on PlayStation 4 and PlayStation 5, but not on PC. As a result, to use Bluetooth audio on PC, you must connect your Bluetooth headset directly to your PC.To pair the Revolution 5 Pro to your Bluetooth headset or earbuds, follow these steps: Put the controller and true wireless earbuds/headset next to each other. Set the Bluetooth true wireless earbuds/headset to pairing mode. Press and hold the Bluetooth button on the controller for six seconds. The controller sets to pairing mode and the light ring around the right joystick flashes in blue and white. When the controller is paired, the halo ring will stop flashing.Future connections of the same true wireless earbuds/headset will pair automatically. To turn on Bluetooth on the controller, press and hold the Bluetooth button for three seconds.NOTE: The Bluetooth feature on the Revolution 5 Pro is only for audio connection. You cannot use it to connect the controller to your console.

Question 15

What is the battery autonomy of the Revolution 5 Pro Controller?

Accepted Answer

You can play for 10 hours or more depending on the power settings. To increase battery life, go to the Revolution 5 Pro app home screen and activate the Battery Saving mode.

Question 16

I can't use my headset with the Revolution 5 Pro Controller in wireless mode

Accepted Answer

The Revolution 5 Pro Controller doesn't support audio when it's set to PC mode and Wireless mode at the same time. However, you can use your headset with the controller set to Wired mode.

Question 17

The LED around the right joystick doesn't turn on

Accepted Answer

Make sure that the Battery Saving mode is disabled. Battery saving disables the following features: Vibration Lighting effects around the right stick Microphone echo cancelling & noise reduction

Question 18

My PC doesn't recognise my Revolution 5 Pro Controller

Accepted Answer

Make sure that your controller is set to PC mode. The Mode switch (on the underside of the controller) must be set to the third position (PC). The Revolution 5 Pro Controller is compatible with all PC games that are XInput compatible.

Question 19

My console doesn't recognise my Revolution 5 Pro Controller

Accepted Answer

If you use the controller in Wired mode: Make sure that the cable is correctly fixed to your controller and connected to your console. Press the PS button to synchronise the controller. Make sure that the platform switch is set to the correct platform. If you use the controller in Wireless mode: Make sure that the battery is charged. Make sure that the controller is connected to the USB Bluetooth receiver. The LED on the receiver and the player LED on the controller must be fixed. Make sure that the USB Bluetooth receiver is connected to your console. Make sure that the platform switch is set to the correct platform. If you switch from Wireless mode to Wired mode, the message "Controller was disconnected" displays on-screen. To reconnect the controller, press the PS button.

Question 20

I can't turn on the console with the Revolution 5 Pro Controller

Accepted Answer

You can turn on or off a PlayStation 4/5 by pressing the PS button only with a Sony DualSense controller. Our controllers do not support this feature.

Question 21

The touchpad of the Revolution 5 Pro Controller doesn't work on PC

Accepted Answer

This is as designed. The touchpad is only compatible with consoles.

Question 22

I can't achieve some movements with the D-pad of my Revolution 5 Pro Controller

Accepted Answer

Connect your controller to a PC. Launch the companion app. Go to Edit profiles > Mapping (iii) and select the eight way movement option. Save your profile and send it to your controller.

Question 23

The Revolution 5 Pro Controller is detected as an Xbox controller on Steam

Accepted Answer

When PC games don't have native PlayStation support, Steam automatically converts controllers' layouts to Xbox inputs. The controller will work, but the controls on screen may display as Xbox buttons.You have several ways to remap your controller: Use Steam Input to edit your controller's layout. Set your controller to Advanced mode and use the Revolution 5 Pro app to define a profile and assign a specific action to each button. Go to the in-game's settings to change the mappings if the option is available.

Question 24

My controller doesn't charge anymore

Accepted Answer

To charge your controller, you must always use the charger/cable supplied with it. As specified in the safety notice, using another cable (like a phone charger for instance) will damage the battery. This kind of damage is not covered by the warranty.

Question 25

Download links for controllers' applications and software

Accepted Answer

You can find all the links to download applications and software for your controllers in the table below. CONTROLLERS LINKS Daija Arcade Stick Windows/Mac OS X Xbox GC-400ES Windows MG-X/MG-X Pro iOS Pro Compact Controller Windows/Xbox Revolution Pro Controller Windows Revolution Pro Controller 2 Windows/Mac OS X Revolution Pro Controller 3 Windows/Mac OS X Revolution Unlimited Pro Controller Windows/Mac OS X Revolution X Pro Controller Windows/Xbox Revolution X Unlimited Controller Windows/Xbox Revolution 5 Pro Controller Windows/Mac OS X Revolution 5 Unlimited Controller Android Wired Compact Controller Windows
