Question 1

How do I update my Revosim devices through the mobile application?

Accepted Answer

Connect the steering wheel, the base and the pedals together. Press the Bluetooth button on the base for three seconds. The LED flashes in blue. Turn on Bluetooth on your phone. Launch the application. The LED on the base displays a solid blue for five seconds to show that the connection is established. From the main menu, press Update available or go to Settings > Update available. Do not turn off the application or the phone and do not touch any of the Revosim devices during the update. The message "Your firmware is up to date" displays.

Question 2

What kind of elastomer cushions should I use on my Revosim Pure steering wheel and pedals?

Accepted Answer

The three elastomer cushions give three different levels of density. You can mix and match them according to your preference and the type of game you're playing. Color Density Usage Recommendations Blue Soft Lifestyle game simulation No hard mounting with pedals Yellow Medium GT game simulation Red Hard F1 game simulation

Question 3

The LED on the Revosim wheel base is blinking red and there is no more force feedback

Accepted Answer

A blinking red LED means that the base detects an unusually high movement. In this situation, it automatically turns off force feedback to protect the user.To fix this issue, restart the base.

Question 4

The LED on the Revosim wheel base displays a fixed red light

Accepted Answer

A fixed red LED means that there is an issue with the base. Make sure that everything is connected to the base and functional. Make sure that the temperature of the base is not too high. The operating temperature must be set between 15 °C and 40 °C. If it is over 40 °C, turn off the base and leave it for at least 30 minutes/1 hour. Restart the base. If you are still having issues, contact our technical support team.

Question 5

Which games is the Revosim Pure steering wheel compatible with?

Accepted Answer

The RS Pure steering wheel is compatible with the following games: Assetto Corsa Assetto Corsa Competizione CarX Street DiRT 5 DiRT Rally 2.0 EA Sports WRC Euro Truck Simulator 2 F1 22 F1 23 F1 24 FIA European Truck Racing Championship Forza Horizon 4 Forza Horizon 5 Forza Horizon 6 FURIDASHI: Drift Cyber Sport iRacing KartKraft Le Mans Ultimate Test Drive Unlimited: Solar Crown WRC 9 WRC 10 WRC Generation Wreckfest To play Assetto Corsa Competizione, you can launch the game directly through the Revosim software.The games Forza Motorsport, rFactor 2 and The Crew Motorfest are still being optimised for full compatibility.

Question 6

The RPM LEDs on the wheel are not working

Accepted Answer

Make sure that you launch the PC application before launching the game.

Question 7

Which platforms is the Revosim Pure steering wheel compatible with?

Accepted Answer

The RS Pure steering wheel is only compatible with Windows 10/11.

Question 8

Are Revosim devices compatible with other brands?

Accepted Answer

We intend to make all our future Revosim devices (steering wheels, pedal sets, bases...) fully intercompatible between ranges, meaning that you could use your Revosim RS Pure steering wheel with another Revosim base for example.However, nothing is currently planned to make our devices compatible with products from other simracing brands.

Question 9

The Revosim wheel base is not correctly calibrated

Accepted Answer

Calibration issues can happen after an update. Open the Revosim app. Go to Customization > Base calibration > Wheel > Wheel center calibration. Follow the on-screen instructions.

Question 10

What is the maximum rotation angle that the Revosim Pure steering wheel can reach?

Accepted Answer

The maximum rotation angle of the wheel is 1,600°. Through the software or application, you can set the rotation angle of your choice according to the car you're driving.

Question 11

The Revosim Pure pedals are not correctly calibrated

Accepted Answer

Calibration issues can happen after an update. Open the Revosim app. Go to Customization > Pedal calibration and select the pedal that you want to calibrate. Follow the on-screen instructions.

Question 12

The Revosim Pure steering wheel isn't mapped automatically

Accepted Answer

Launch the Revosim mobile app. Go to the Rally profile and to the Wheel section. Set the value of the right paddle to 5.

Question 13

Where can I download the Revosim app?

Accepted Answer

You can download the software for Windows here, and the application on the App Store for iOS or on Google Play for Android.

Question 14

How do I update my Revosim Pure devices through my PC?

Accepted Answer

Connect the steering wheel, the base and the pedals together. Connect the base to your PC with the USB-C cable. Launch the Revosim software. In the Updates section, click Check for Firmware updates. Click Update available. Do not turn off your PC and do not touch any of the Revosim devices during the update. The message "Up-to-date" displays below the devices.

RS Pure Kit without pedals

Documents & downloads

Frequently asked questions

Top-rated profiles

Need help?

Color	Density	Usage Recommendations
Blue	Soft	Lifestyle game simulation No hard mounting with pedals
Yellow	Medium	GT game simulation
Red	Hard	F1 game simulation
